Question 9

Find all the sides and the angles of the quadrilateral obtained by joining two equilateral triangles with sides 4 cm.

Solution

We can form a quadrilateral by joining two equilateral triangles along one of their sides.

Step 1 — Understanding Equilateral Triangles

Let us start with what we know about an equilateral triangle. An equilateral triangle is a triangle where all three sides are equal in length. Also, all three angles inside an equilateral triangle are equal.

We are given two equilateral triangles. Each has sides of 4 cm.

Since all angles in an equilateral triangle are equal, and the sum of angles in any triangle is $180^\circ$ :

$\text{Each angle} = \frac{180^\circ}{3}$

$= 60^\circ$

$\boxed{\text{Each angle of an equilateral triangle} = 60^\circ}$

Diagram 1

Step 2 — Finding the Sides of the Quadrilateral

Let us imagine we join two such equilateral triangles, say $\triangle ABC$ and $\triangle ADC$ , along their common side $AC$ . This creates a new shape, a quadrilateral $ABCD$ .

From $\triangle ABC$ , we know its sides are: $AB = 4 \text{ cm}$ $BC = 4 \text{ cm}$ $AC = 4 \text{ cm}$

From $\triangle ADC$ , we know its sides are: $AD = 4 \text{ cm}$ $CD = 4 \text{ cm}$ $AC = 4 \text{ cm}$

The quadrilateral $ABCD$ has four outer sides: $AB$ , $BC$ , $CD$ , and $DA$ . Let us list their lengths: $AB = 4 \text{ cm}$ $BC = 4 \text{ cm}$ $CD = 4 \text{ cm}$ $DA = 4 \text{ cm}$

$\boxed{\text{All sides of the quadrilateral ABCD are 4 cm}}$

Step 3 — Finding the Angles of the Quadrilateral

Now, let us find the angles of the quadrilateral $ABCD$ . The angles of the quadrilateral are $\angle A$ , $\angle B$ , $\angle C$ , and $\angle D$ .

Angle $A$ of the quadrilateral is $\angle DAB$ . This angle is formed by combining $\angle BAC$ from $\triangle ABC$ and $\angle DAC$ from $\triangle ADC$ . $\angle DAB = \angle BAC + \angle DAC$ $= 60^\circ + 60^\circ$ $= 120^\circ$

Angle $C$ of the quadrilateral is $\angle BCD$ . This angle is formed by combining $\angle BCA$ from $\triangle ABC$ and $\angle DCA$ from $\triangle ADC$ . $\angle BCD = \angle BCA + \angle DCA$ $= 60^\circ + 60^\circ$ $= 120^\circ$

Angle $B$ of the quadrilateral is $\angle ABC$ . This is one of the angles of $\triangle ABC$ . $\angle ABC = 60^\circ$

Angle $D$ of the quadrilateral is $\angle ADC$ . This is one of the angles of $\triangle ADC$ . $\angle ADC = 60^\circ$

Answer

(i) The sides of the quadrilateral ABCD are 4 cm each. (ii) The angles of the quadrilateral ABCD are angle A = 120 degrees, angle B = 60 degrees, angle C = 120 degrees and angle D = 60 degrees.
