Question 5

1. State which pairs of triangles in Fig. 6.34 are similar. Write the similarity criterion used by you for answering the question and also write the pairs of similar triangles in the symbolic form :

2. In Fig. 6.35, $\Delta \text{ODC} \sim \Delta \text{OBA}$, $\angle \text{BOC} = 125^\circ$ and $\angle \text{CDO} = 70^\circ$. Find $\angle \text{DOC}$, $\angle \text{DCO}$ and $\angle \text{OAB}$.

3. Diagonals AC and BD of a trapezium ABCD with $\text{AB} \parallel \text{DC}$ intersect each other at the point O. Using a similarity criterion for two triangles, show that $\frac{\text{OA}}{\text{OC}} = \frac{\text{OB}}{\text{OD}}$.

4. In Fig. 6.36, $\frac{\text{QR}}{\text{QS}} = \frac{\text{QT}}{\text{PR}}$ and $\angle 1 = \angle 2$. Show that $\Delta \text{PQS} \sim \Delta \text{TQR}$.

6. In Fig. 6.37, if $\Delta \text{ABE} \cong \Delta \text{ACD}$, show that $\Delta \text{ADE} \sim \Delta \text{ABC}$.

7. In Fig. 6.38, altitudes AD and CE of $\Delta \text{ABC}$ intersect each other at the point P. Show that:

(i) $\Delta \text{AEP} \sim \Delta \text{CDP}$ (ii) $\Delta \text{ABD} \sim \Delta \text{CBE}$ (iii) $\Delta \text{AEP} \sim \Delta \text{ADB}$ (iv) $\Delta \text{PDC} \sim \Delta \text{BEC}$

8. E is a point on the side AD produced of a parallelogram ABCD and BE intersects CD at F. Show that $\Delta \text{ABE} \sim \Delta \text{CFB}$.

9. In Fig. 6.39, ABC and AMP are two right triangles, right angled at B and M respectively. Prove that:

(i) $\Delta \text{ABC} \sim \Delta \text{AMP}$ (ii) $\frac{\text{CA}}{\text{PA}} = \frac{\text{BC}}{\text{MP}}$

10. CD and GH are respectively the bisectors of $\angle \text{ACB}$ and $\angle \text{EGF}$ such that D and H lie on sides AB and FE of $\Delta \text{ABC}$ and $\Delta \text{EFG}$ respectively. If $\Delta \text{ABC} \sim \Delta \text{FEG}$, show that:

(i) $\frac{\text{CD}}{\text{GH}} = \frac{\text{AC}}{\text{FG}}$ (ii) $\Delta \text{DCB} \sim \Delta \text{HGE}$ (iii) $\Delta \text{DCA} \sim \Delta \text{HGF}$

In Fig. 6.40, E is a point on side CB produced of an isosceles triangle ABC with AB = AC. If AD $\perp$ BC and EF $\perp$ AC, prove that $\Delta$ ABD $\sim$ $\Delta$ ECF.

Sides AB and BC and median AD of a triangle ABC are respectively proportional to sides PQ and QR and median PM of $\Delta$ PQR (see Fig. 6.41). Show that $\Delta$ ABC $\sim$ $\Delta$ PQR.

D is a point on the side BC of a triangle ABC such that $\angle$ ADC = $\angle$ BAC. Show that $\text{CA}^2 = \text{CB.CD}$.

Sides AB and AC and median AD of a triangle ABC are respectively proportional to sides PQ and PR and median PM of another triangle PQR. Show that $\Delta$ ABC $\sim$ $\Delta$ PQR.

A vertical pole of length 6 m casts a shadow 4 m long on the ground and at the same time a tower casts a shadow 28 m long. Find the height of the tower.

If AD and PM are medians of triangles ABC and PQR, respectively where $\Delta$ ABC $\sim$ $\Delta$ PQR, prove that

$\frac{\text{AB}}{\text{PQ}} = \frac{\text{AD}}{\text{PM}}$
