Question 3

Why should the extension of the vertical and horizontal sides of the original square pass through the vertices of the dotted square?

[Hint: From the diagonal property of a square, the line that bisects an angle passes through the opposite vertex. Argue why the vertical and horizontal sides of the original square bisect the two angles of the dotted square.**]

Solution

The extensions of the solid square's sides form the axes, which are the diagonals of the dotted square.

Step 1 — Setting up the coordinate system

Let us place the common vertex of the solid square and the center of the dotted square at the origin, which is point $O(0,0)$ . The solid square has its sides perfectly horizontal and vertical. So, the line extending from its horizontal side is the x-axis. The line extending from its vertical side is the y-axis.

Diagram 1

Step 2 — Understanding angle bisectors in a square

Let the dotted square be $ABCD$ . Its center is $O$ . Each corner (vertex) of a square has an angle of $90^\circ$ . A special property of a square is that its diagonals bisect these vertex angles. For example, the diagonal $AC$ bisects the angle at vertex $A$ and also the angle at vertex $C$ . Similarly, the diagonal $BD$ bisects the angle at vertex $B$ and the angle at vertex $D$ .

Step 3 — Connecting the extensions to the diagonals

We know the x-axis and y-axis are perpendicular lines. They pass through the center $O$ of the dotted square. The hint asks us to argue that the x-axis and y-axis (extensions of the solid square's sides) bisect two angles of the dotted square. If the x-axis bisects an angle of the dotted square, it must be one of its diagonals. If the y-axis bisects another angle of the dotted square, it must be the other diagonal. Since the diagonals of a square are perpendicular and intersect at its center, it makes perfect sense for the x-axis and y-axis to be the diagonals of the dotted square.

Step 4 — Concluding the position of the vertices

If the x-axis is a diagonal of the dotted square, then two of its vertices must lie on the x-axis. If the y-axis is the other diagonal of the dotted square, then the other two vertices must lie on the y-axis. This means all four vertices of the dotted square are located on either the x-axis or the y-axis. Since the x-axis is the extension of the horizontal side of the original square, it passes through two vertices of the dotted square. Since the y-axis is the extension of the vertical side of the original square, it passes through the other two vertices of the dotted square. Therefore, the extensions of the vertical and horizontal sides of the original square pass through the vertices of the dotted square.

Answer

The common vertex of the solid square is the center of the dotted square. The extensions of the solid square's horizontal and vertical sides form two perpendicular lines (the x-axis and y-axis). These lines pass through the center of the dotted square. For these lines to bisect the vertex angles of the dotted square (as suggested by the hint), they must be the diagonals of the dotted square. Since the vertices of a square lie on its diagonals, the extensions of the original square's sides must pass through the vertices of the dotted square.
